| Place of Origin | Zhengzhou China |
| Trademark | BOSDI |
| Minimum Order | 50 Pcs |
| Delivery Time | 3-5 days |
| Payment Terms | T/T, L/C, Western Union, MoneyGram, Paypal |
| Supply Ability | 1,000,000 Pcs/ year |
| Price | Negotiable |
| Package | Carton, Plastic drum/bag, Pallet |
1. High precision, can be used for precision grooving and cutting, can reduce processes, cutting surface quality is good.
2. Narrow slits can greatly improve the utilization of raw materials.
3. High efficiency and sharp cutting.
4. High rigidity, high strength, long service life.
5. The matrix has strong bearing capacity and is not easy to deform.
Diamond process division:
1. Sintered diamond cutting piece: It is made of cold pressing sintering and hot pressing sintering.
2. Welding of diamond cutting pieces: there are two types: high-frequency welding and laser welding. High frequency welding uses high temperature melting medium to weld the cutter head and the substrate together. Laser welding uses high temperature laser beam to melt the contact edge of the cutter head and the substrate to form metallurgical bonding.
3. Electroplated diamond cutting blade: it is used to attach the cutter head powder to the substrate by electroplating.
Classification of cutting pieces
1. Continuous edge saw blade: continuous sawtooth diamond cutting blade is generally made by sintering. Bronze bond is commonly used as the base matrix material. Water must be added to ensure the cutting effect when cutting. The type of gap cut by laser blade is also available.
2. Knife head type cutting slice: sawtooth is broken, cutting speed is fast, suitable for dry and wet cutting methods.
3. Turbine type cutting blade: combining the advantages of the first two items, the sawtooth continuously presents turbine like uniform convex concave, which improves the cutting speed and increases the service life.
It is applicable to the cutting of terrazzo marble.
Cutting of cement pavement, hard refractory materials and non-metallic materials.
Wall decoration and grooving, and grooving of roads and bridges.
Carving of pavement, wall and bridge deck.
Widely used in home decoration, municipal construction, road reconstruction, airport runway construction, concrete pavement and other construction sites, especially suitable for professional cutting operations such as asphalt and concrete pavement joint cutting
It is applicable to the cutting of terrazzo marble.
Cutting of cement pavement, hard refractory materials and non-metallic materials.
Wall decoration and grooving, and grooving of roads and bridges.
Carving of pavement, wall and bridge deck.
Widely used in home decoration, municipal construction, road reconstruction, airport runway construction, concrete pavement and other construction sites, especially suitable for professional cutting operations such as asphalt and concrete pavement joint cutting
|
OD mm |
ID mm |
Segent thickness mm |
Segmented height mm |
|
105 |
20 |
1.4 |
7.5 |
|
115 |
22.23 |
1.4 |
8.0 |
|
125 |
22.23 |
1.4 |
8.0 |
|
150 |
25.4 |
1.6/2.0 |
8.0/10.0 |
|
180 |
25.4 |
1.6/2.0 |
8.0 |
|
200 |
25.4 |
1.7/2.0 |
8.0 |
|
250 |
25.4 |
1.7/2.0 |
8.0 |
|
300 |
25.4 |
2.2 |
8.0 |
|
350 |
25.4 |
2.4 |
8.0 |
