| Place of Origin : | Zhengzhou China |
| Trademark : | BOSDI |
| Minimum Order : | 5 Pcs |
| Delivery Time : | 3-5 days |
| Payment Terms : | T/T, L/C, Western Union, MoneyGram, Paypal |
| Supply Ability : | 100,000 Pcs per year |
| Price : | Negotiable |
| Package : | Carton, Plastic drum/bag, Metal bucket |
PCD composite sheet is made of diamond powder and cemented carbide matrix sintered at high remperature and high pressure.Compare with cemented carbide cutter,the PCD made with fine Compare with cemented carbide cutter, the PCD made with fine processing,which has 8-12 times hardness; thermal conductivity is 1.5-9 times that of cemented carbide,or even higher than PCBN and copper,so the tool heat transfer is rapid;friction coefficient is generally only one third of cemented carbide, so PCD tool cansignificantly reduce cutting force;thermal expansion coefficient is equivalent to 1/5 of cemented carbide,so PCD tool thermal deformation is small and machining accuracy is high.
PCD the affinity between cutting tools and non-ferrous metals and non-metallic materials is very small, it is not easy to form chip nodules during processing.Can be widely used in all kinds of non-ferrous metals,alloy materials, wood,rubber,ceramics,plastics,refractories and high-hardness composite processing field,but also can be used to manufacture all kinds of instruments and equipment support,wear-resistant parts.
The diamond content of PCD composite sheet produced by our company is more than ≥90%,which has high hardness,good impact toughness,good stability and excellent product rate of 95%, especially in the stability of ultra-thin diamond layer,which is an ideal composite superhard material to realize the replacement grinding by car and low cost cutting.Our company can also according to customer needs,all kinds of special-shaped products processing customized.
BD-A series of diamond composite sheets for processing non-ferroic metal materials
It is suitable for the processing of non-iron metal and alloy aluminum alloy,graphite and other composite materi-als,and has the characteristics of high wear resistance,strong toughness,super high surface finish and so on.
| Model No. | Size um | Diamond mm | Thickness layer mm | Total thickness mm |
| BD-A1 | 2 | 55 | 0.4-0.65 | 1.6/2.0/3.2 |
| BD-A2 | 5 | 55 | 0.4-0.65 | 1.6/2.0/3.2 |
| BD-A3 | 10 | 55 | 0.4-0.65 | 1.6/2.0/3.2 |
| BD-A4 | 25 | 55 | 0.4-0.65 | 1.6/2.0/3.2 |
| BD-A5 | 302 | 55 | 0.4-0.65 | 1.6/2.0/3.2 |
Aluminum-copper cutting diamond composite sheet has fine grain, medium grain,coarse grain and mixed grain size to choose from,according to customer needs,all kinds of special-shaped products processing customized.
※ core advantages:super wear resistance.
※ main raw materials:diamond powder,cemented carbide.
※ key technologies:high temperature and high pressure,metal powder catalyst,precision ※ measurement and control.
※ application field:for manufacturing cutting tools,suitable for cutting non-iron raw materials,widely used aluminum alloy,broken bridge aluminum,copper alloy,graphite block,graphite column and other fields.
Diamond Composite Sheet for BD-B Series Woodworking Tools
It is suitable for the processing of composite material,aggrandizement floor,solid wood and so on.It has the characteristics of high wear resistance,good toughness and good surface finish.
| Model No. | Size um | Diamond mm | Thickness layer mm | Total thickness mm |
| BD-B3 | 10 | 55 | 0.4-0.65 | 1.6/2.0/3.2 |
| BD-B4 | 25 | 55 | 0.4-0.65 | 1.6/2.0/3.2 |
| BD-B5 | 302 | 55 | 0.4-0.65 | 1.6/2.0/3.2 |
The diamond composite sheet used for woodworking cutting tools has fine grain,medium grain,coarse grain and mixed grain size to choose from.
※ core advantages:super wear resistance,super sharpness.
※ main raw materials:diamond powder,cemented carbide.
※ key technologies:high temperature and high pressure,metal powder catalyst,precision measurement and control.
※ application field:all kinds of solid wood and solid wood multi-layer floor,PVC plastic floor,high density fiberboard, density board,particleboard and other woodworking cutting saw blade,finishing knife,edge cutting knife,molding knife,edge cutting knife and so on and the requirements of high wear resistance woodworking milling cutter.
BD-G series of diamond composites for precision machining
Applicable to 3C industry,precision electronic components,aerospace equipment processing,with high wear resistance,toughness and other characteristics.
| Model No. | Size um | Diamond mm | Thickness layer mm | Total thickness mm |
| BD-G1 | 2 | 55 | 0.15-0.35 | 0.4/0.6/0.8 |
| BD-G2 | 5 | 55 | 0.15-0.35 | 0.4/0.6/0.8 |
| BD-G3 | 10 | 55 | 0.3-0.5 | 0.4/0.6/0.8 |
| BD-G4 | 25 | 55 | 0.4-0.6 | 0.4/0.6/0.8 |
| BD-G5 | 302 | 55 | 0.4-0.6 | 0.4/0.6/0.8 |
The diamond composite sheet for precision machining has fine grain, medium grain, coarse grain and mixed grain size to choose from.
※ Core advantages:diamond layer is ultra-thin,diamond distribution is uniform,composite layer control is excellent.
※ Main raw materials:diamond powder,cemented carbide.
※ Key technologies:high temperature and high pressure,metal powder catalyst,precision measurement and control.
※ Application field:used in manufacturing cutting tools, widely used in 3C industry precision electronic components, such as integrated circuit boards,mobile phone shells and other high-precision medical devices,aerospace equipment and other fields.
